Operations

Operations are the individual actions in a flow. They enable you to do things like manage data within Directus, transform the flow's data, send information off to outside services, set conditional logic, trigger other flows, and more.

Condition

A condition operation lets you choose a success path or failure path by validating data passed into it with Filter Rules.

Options

• Condition Rules — Create conditions with Filter Rules.

Payload

This operation does not generate data. If the filter rule is configured properly, it will append a null value on its operationKey, regardless of if the condition was met or not. However, if the filter rule is misconfigured, it will append an array containing an object you can use to help debug the misconfiguration.

Run Script

This operation lets you add a custom script using vanilla JavaScript or TypeScript. The script will be executed securely in an isolated sandbox. No interactions take place between the sandbox and the host except for sharing input and output values. This means, for example, no access to the file system and no ability to do network requests.

Options

The operation provides a default function template. The optional data parameter lets you pass in the data chain as an argument.

Payload

The function's return value will be appended under its <operationKey>.

More Details

As an example, let's say you have this function in a script operation, named myScript.

// A key from the data chain
{
    "previousOperation": {
        "value": 5
    }
}

Then you add the following logic via Run Script.

// Your function in the myScript operation
module.exports = function (data) {
    return {
        timesTwo: data.previousOperation.value * 2,
    };
};

The returned value will be appended under the myScript operation key.

{
    "previousOperation": {
        "value": 5
    },
    "myScript": {
        "timesTwo": 10
    }
}

Create Data

This operation creates item(s) in a collection.

Options

• Collection — Select the collection you'd like to create items in.
• Permissions — Select the scope of permissions used for this operation.
• Emit Events — Toggle whether the event is emitted.
• Payload — Defines the payload to create item(s) in a collection.

Payload

An array with the ID(s) of all items created will be appended under its <operationKey>.

Read Data

This operation reads items from a collection and adds them onto the data chain. You may select Items by their ID or by running a query.

Options

• Permissions — Set the scope of permissions used for this operation.
• Collections — Select the collection you'd like to read items from.
• IDs — Input the ID for items you wish to read and press enter. Click the ID to remove.
• Query — Select the items with a query. To learn more, see Filter Rules.
• Emit Events — Toggle whether the event is emitted.

Payload

An array containing all items read will be appended under its <operationKey>.

Update Data

This operation updates item(s) in a collection. You may select item(s) to update by their ID or by running a query.

Options

• Collection — Select the collection on which you'd like to update items in.
• Permissions — Set the role that this operation will inherit permissions from.
• Emit Events — Toggle whether the event is emitted.
• IDs — Input the ID for Item(s) you wish to update and press enter. Click the ID to remove.
• Payload — Update Items in a collection, using one of the following formats:
  • Single object with data, to update items specified in IDs or Query to the same values.
  • Single object with keys and data, to update multiple items to the same values.
  • Array of objects with data including primary keys, to update multiple items to different values.
  • To learn more, see our Items API reference.
• Query — Select items to update with a query. To learn more, see Filter Rules.

Payload

An array containing all items updated will be appended under its <operationKey>.

Delete Data

This operation deletes item(s) from a collection.

Options

• Collection — Select the collection you'd like to delete items from.
• Permissions — Set the scope of permissions used for this operation.
• Emit Events — Toggle whether the event is emitted.
• IDs — Set Item IDs and press enter to confirm. Click the ID to remove.
• Query — Select items to delete with a query. To learn more, see Filter Rules.

Payload

An array with the ID(s) of all items deleted will be appended under its <operationKey>.

JSON Web Token (JWT)

This operation lets you sign and verify a JSON Web Token (JWT) using the jsonwebtoken package.

Options

• Operation — Select the operation you'd like to perform.
• Payload — The string or JSON payload to sign.
• Token — The JSON Web Token to verify or decode.
• Secret — The secret key used to sign or verify a token.
• Options — The options object provided to the operation. For the list of available options, see the documentation of jsonwebtoken.

Payload

Based on the operation selected, a JSON Web Token (JWT) or payload will be appended under its <operationKey>.

Log to Console

This operation outputs information to the server-side console as well as the Logs within the Data Studio. This is a key tool for troubleshooting flow configuration. A log operation's key will have a null value on the data chain.

Options

• Message — Sets a log message.

Payload

This operation does not generate data for the data chain as its messages are for debugging and troubleshooting. It will append a null value on the operationKey.

Send Email

This operation sends emails off to one or more addresses specified.

Options

• To — Sets the email addresses. Hit enter to save the email. Click on a pill to remove it.
• Subject — Set the subject line.
• Body — Use a Markdown or WYSIWYG editor to create the email body.

Payload

This operation does not generate data for the data chain. It will append a null value on the operationKey.

More Details

Send Notification

This operation pushes notifications to Directus Users. If the operation executes successfully, a list containing the IDs of all sent notifications generated is appended under this operation's key.

Options

• Users — Define a user by their UUID. Hit enter to save it. Click on a pill to remove it.
• Permissions — Define the role that this operation will inherit permissions from.
• Title — Set the title of the notification.
• Message — Set the main body of the notification.

Payload

This operation does not generate data. It will append a null value on its operationKey.

More Details

Webhook / Request URL

This operation makes a request to another URL.

Options

• Method — Choose to make a GET, POST, PATCH, DELETE, or other type of request.
• URL — Define the URL to send the request to.
• Headers — Create a new header:value to pass along with the request.
• Request Body — Set the request body's data.

Payload

When an operation completes successfully, the response is appended under its <operationKey>.

Sleep

This operation creates a delay in the Flow for a given amount of milliseconds, then continues to the next operation.

Options

• Milliseconds — Define the number of milliseconds to sleep.

Payload

This operation does not generate data. It will append a null value on its operationKey.

Transform Payload

This operation lets you custom define your own JSON payload for use in subsequent operations. This enables you to take multiple sources of data and consolidate them into a single payload.

Options

• JSON — Define JSON to insert into the data chain.

Payload

When an operation completes successfully, the value you defined under the JSON configuration operation is appended onto its operationKey.

Trigger Flow

This operation starts another flow and (optionally) passes data into it. It should be used in combination with the Another Flow trigger.

Options

• Flow — Define a flow by its primary key UUID.
• Payload — Defines a JSON payload to pass into $trigger on the flow it triggered.

Payload

If you've configured a response body in the trigger of the other flow, this will be appended under this operationKey. If no response body is configured, null is appended under this operationKey.

More Details
